Profi C System Utilities Terminal Drivers

Terminal Drivers

1. TERMINAL DRIVER DEFINITIONS

Choice #1 from the Terminal Definition Menu brings you to the Terminal Driver Definitions Screen (also known as the Terminal Control File Maintenance Screen). Hexadecimal Codes are used for the display assignments including color assignment and may be found in the appropriate terminal manual.

Below is an illustration of the Terminal Control File Maintenance Screen followed by an explanation of the fields.

FIG. SY.12

File (:ommands Edit Screen Help

SY.TERM

Terminal Control File Maintenance

Time and Date

Profi'C Software (tm)

Profi'C Term Code

1. Description

2. Operating Environ.

2. Pick TenninalCode

3. Video Type D,C,M

4. Record Def. Types

11. Video Escape Codes

12. Graphic Escape Codes

13. Color Espace Codes

14. Cursor Key Escape Codes

15. Unshifted Function Key Codes

16. Shifted Function Key Codes

17. Function Key Label Codes

"EXPLANATIONS

Profi'C Term Code. You must enter a code for the type of terminal you are entering data for (for example,

"W" for Wyse).

1. Description. Enter a description of the terminal up to 35 characters, such as "Wyse 50 Terminal".

2. Operating Environ. Enter the name of the operating system (or data base system) for this terminal.

3. Pick Terminal Code. This is the code the operating system uses. Refer to the Pick manual.

4. Video Type D,C,M. Enter the terminal's color type: "M"onochrome, "C"olor, or <RTN~ for neither.

5. Record Def. Type. Enter "U" if this data is for a particular user, "D" if you are entering driver definitions

for a specific terminal, or "P" if it is for a particular port.

Afteryou enter the Record Definition Type, the system will display the Video Escape Codes Windowand the Prompt: "Do you want to add this record? Y/N." If you want to add hexadecimal codes for the Video Escape fields, enter "Y" and begin to enter the codes found in the terminal's manual. Or if you do not want to enter any codes, enter "N" <RTN>. Below is an example.

1. Video Dim

2. Reverse Video

3. Normal Video

4. Video On

5. Video Off

6. Auxiliary Port On

7. Auxiliary PortOff

8. Video Blink On

9. Video Blink Off

After you enter all the Video Escape Codes or if you entered "N" (not to enter any codes), the system will bring you to the Graphic Escape Codes Window and the Prompt: "Do you want to add this record? Y/N". If you want to add hexadecimal codes for the Graphic Escape fields, enter "Y" and begin to enter the codes found in the terminal's manual. Or you may enter "N" if you do not wish to enter any codes. After entering codes for each window, the system will display the Prompt: "Enter <RTN> to save, field#, <D>el or <E>xit without save:". If you need to make a correction to a field in the window, enter the number of the field and make the change. On the next page is an example of the Graphic Escape Codes Window.

- SY.390101

System Utilities Terminal Control File Maintenance SY.20

Graphic Character Escape Codes

1. Upper

Left r

2. Uper

Right ~

3. Lower

Left L

4. Lower

Rght J

5. Horiz.

Ln.

6. Vert.

Ln. 1

7. Cross

8. Top

Cross T

Bot.Cross 1

10. Left

Cross ,1

11. Rght

Cross ~

12. Horiz.

Bar =

13.

Graphics On

14.

Graphic Off

184802

184803

After you finish entering all the Graphic Escape Codes or if you entered "N" (not to enter any codes), the system will bring you to the Color Escape Codes Window and the Prompt: "Do you want to add this record? Y/Nn. If you want to add hexadecimal codes for the ColorEscape fields, enter "Y" and begin to enter the codes found in the terminal's manual. Or you may enter "N" if you do not wish to enter any codes. Below is an illustration of the Color Escape Codes Window.

Black

White

Brown

Red

Green

Blue

Cyan

Magenta

Full Intensity

Foreground l

Half Intensity Foreground

Background

3 6 9

SY.390101
